Vistar Electronics supplies a complete range of slide switches – SPST, SPDT, DPST and DPDT circuits in 2‑position or 3‑position configurations. Available in SMT, DIP through‑hole, right‑angle, vertical and panel mount termination. Rated 0.5A–5A at up to 125V AC / 30V DC with 10,000 mechanical cycles. Gold‑plated or silver contacts, UL94‑V0 housings. RoHS 3 & REACH compliant. Free samples available for qualified projects.
| Parameter | Signal‑Grade Series | Power‑Grade Series |
|---|---|---|
| Circuit Configurations | SPST / SPDT / SP3T | DPST / DPDT / DP3T |
| Positions | 2‑position (ON‑ON) / 3‑position (ON‑OFF‑ON) | 2‑position (ON‑ON) / 3‑position (ON‑OFF‑ON) |
| Actuator Type | Standard slide knob / flush actuator | Extended slide knob / panel mount lever |
| Termination Styles | SMT / DIP Through‑Hole / Right‑Angle / Vertical | DIP Through‑Hole / Right‑Angle / Panel Mount / Solder Lug |
| Current Rating | 0.5A | 3A – 5A |
| Voltage Rating | 12V DC – 30V DC | 125V AC – 250V AC / 30V DC |
| Contact Resistance | ≤ 50mΩ (initial) | |
| Insulation Resistance | ≥ 100MΩ at DC 100V | |
| Dielectric Withstanding Voltage | 500V AC for 1 minute | 1000V AC – 1500V AC for 1 minute |
| Mechanical Life | 10,000 cycles (min) | |
| Contact Material | Gold‑plated Phosphor Bronze (low‑current signal) | Silver‑plated Brass / Copper Alloy |
| Housing Material | High‑Temp LCP / PBT / PA9T, UL94‑V0 | |
| Actuator Travel | 2.0mm – 4.0mm (depending on series) | |
| Actuator Height Options | Flush (0mm raised) / Standard (2–5mm) / Extended (6mm+) | |
| Operating Temperature | -40°C to +85°C | |
| Compliance | RoHS 3, REACH, ISO 9001:2015 | |
Available in SPST, SPDT, SP3T, DPST, DPDT and DP3T circuits – from simple single‑pole on/off switching to complex double‑pole three‑position control. SPDT (3‑pin) and SP3T (4‑pin) for signal routing; DPDT (6‑pin) and DP3T (8‑pin) for motor direction control and dual‑circuit switching.
2‑position slide switches provide simple binary switching (ON‑ON) for mode selection between two states. 3‑position slide switches add a centre‑off position (ON‑OFF‑ON) for forward‑off‑reverse motor control, three‑state logic selection, or multi‑function mode switching – widely used in industrial controls and audio equipment.
SMT (tape‑and‑reel) for automated pick‑and‑place assembly. DIP Through‑Hole for maximum mechanical retention. Right‑Angle (90°) for edge‑mount PCB access – ideal for handheld devices. Vertical for top‑accessible slide actuators. Panel mount with threaded bushings for front‑panel integration.
Gold‑plated phosphor bronze contacts (signal‑grade series) provide ultra‑low contact resistance (≤ 50mΩ) and superior corrosion protection for low‑current digital logic switching. Silver‑plated contacts (power‑grade series) offer higher current carrying capacity (up to 5A) and excellent arc resistance for AC mains switching.
Engineered with positive detent mechanisms that provide distinct tactile “click” feedback at each switch position, confirming actuation to the user even behind panel overlays or in high‑vibration environments. Available with shorting (make‑before‑break) or non‑shorting (break‑before‑make) contact options as documented by C&K Switches[reference:5].
All Vistar slide switches are manufactured under ISO 9001:2015 and fully comply with RoHS 3 (EU Directive 2015/863) and REACH SVHC regulations. Our REACH‑compliant switches contain zero SVHC substances above 0.1% weight threshold, protecting your products from market access barriers and costly recalls[reference:6]. Full compliance certificates available upon request.
Specialized in electronic connectors since 2009
100% quality testing before shipment
Available for qualified projects
2-4 weeks standard delivery
Custom design & manufacturing
Serving 50+ countries worldwide
Shenzhen Vistar Electronics Co., Ltd. is a professional slide switch manufacturer based in Pingshan District, Shenzhen, China – the global electronics manufacturing hub. Since 2009, we have specialized in the design, manufacturing, and global supply of electromechanical switching solutions, including slide switches, tactile switches, pushbutton switches, rocker switches, and detector switches for OEM and ODM customers in 50+ countries.
Our slide switch portfolio covers SPST, SPDT, DPST and DPDT circuits in 2‑position (ON‑ON) and 3‑position (ON‑OFF‑ON) configurations. Pin counts include 3‑pin (SPDT), 6‑pin (DPDT), 4‑pin (SP3T), and 8‑pin (DP3T) layouts. Termination styles include SMT (tape‑and‑reel for automated pick‑and‑place), DIP Through‑Hole (wave soldering), Right‑Angle (90°) (edge‑mount), Vertical (top‑accessible), and Panel Mount (front‑panel). Actuator heights range from flush (0mm raised) to extended (6mm+). Current ratings span 0.5A (signal‑grade) to 5A (power‑grade) with voltage ratings up to 125V AC / 30V DC. Mechanical life is rated 10,000 cycles minimum, with gold‑plated or silver‑plated contacts delivering contact resistance ≤ 50mΩ and insulation resistance ≥ 100MΩ at DC 100V. Operating temperature range extends from -40°C to +85°C.
For authoritative technical background, we recommend consulting global industry resources: C&K Switches offers comprehensive slide switch families with positive detent, sealing, and shorting or non‑shorting contacts, providing design flexibility in size, mounting, actuation types, ratings and packages. CUI Devices slide DIP switches feature 1.27 mm or 2.54 mm pitches, 1 to 12 position options, surface mount or through‑hole mounting styles, and operating temperatures from -40°C up to +85°C. These references validate Vistar‘s alignment with internationally recognized switching specifications and reliability standards.
All Vistar slide switches are manufactured under an ISO 9001:2015 certified quality management system, fully compliant with RoHS 3 (EU Directive 2015/863) and REACH SVHC regulations. Our REACH‑compliant switches are verified to contain zero SVHC substances above the 0.1% weight threshold, protecting your electronics from market access barriers and costly recalls.
