I. Overview of Vertical USB-C Connector 24 Pin SMT Straight
This vertical USB-C connector is an ideal choice for designing motherboards, docking stations, industrial control boards, or consumer electronics. Its 24-pin full-featured design ensures compatibility with the latest USB standards (including USB4), while the SMT (Surface Mount Technology) package perfectly suits high-speed automated production lines, reducing manufacturing costs.
II. Key Features and Benefits
- Full-Featured 24 Pins: Includes all necessary power (VBUS), ground (GND), high-speed data (TX/RX), configuration channel (CC), and sideband use (SBU) pins, supporting reversible plugging, PD fast charging (up to 100W), and high-speed data transfer.
- Vertical SMT Mounting: The 90-degree vertical orientation saves lateral space on the PCB, making it suitable for stacked or compact internal layouts.
- High Reliability: Rated current 5A, rated voltage 30V DC, mating cycle life 10,000 cycles, ensuring long-term stable connection.
- Easy Production: Packaged in Reel or Tray, compatible with automated pick-and-place machines.
III. Technical Specifications
| Parameter | Specification | Description |
|---|---|---|
| Manufacturer Model | USB-TC24-F18 | For procurement and inquiries |
| Pin Count | 24 Pin (Full Featured) | Supports all USB-C protocols |
| Mounting Type | Vertical, SMT (Surface Mount) | Solders vertically/perpendicularly onto PCB surface |
| Rated Current | 5A | Supports high-power USB PD charging |
| Rated Voltage | 30V DC | |
| Insertion Force | 20N Max | |
| Withdrawal Force | 5-20N | |
| Mechanical Life | 10,000 Cycles | |
| Packaging | Reel / Tray | Suitable for automated production |
IV. Application Scenarios
- Smartphone and tablet motherboards
- Laptops, Docking Stations
- Industrial control panels, industrial PCs
- IoT gateways, smart home hubs
- In-vehicle infotainment systems (automotive grade verification needed)
