Waterproof USB-C 6 Pin SMT Receptacle — IP67 Right Angle Type-C Connector (USB-TC06-FW06)
Part No: USB-TC06-FW06 | 5A / 30V | 10,000 Cycles | IP67
Waterproof USB-C Receptacle Overview
The waterproof USB-C 6 pin SMT receptacle (USB-TC06-FW06) is a rugged IP67-rated Type-C female connector designed for outdoor, marine, and industrial applications where moisture and dust resistance are critical. Its 6-pin configuration retains VBUS, GND, and CC pins, supporting USB Power Delivery fast charging while eliminating data transfer lines for cost-effective, pure power solutions.
With an IP67 ingress protection rating, this USB-C connector is fully dust-tight and can withstand immersion in 1 meter of water for 30 minutes. The right-angle SMT design allows for space-saving PCB mounting, while the stainless steel shell and silicone sealing ensure long-term reliability in harsh environments. Rated at 5A / 30V DC and 10,000 mating cycles, it is ideal for outdoor power banks, marine electronics, industrial handheld devices, and EV charging stations.
Waterproof USB-C 6 Pin SMT — Technical Specifications (USB-TC06-FW06)
| Parameter | Value | Notes |
|---|---|---|
| Part Number | USB-TC06-FW06 | Standard catalog item |
| Protection Rating | IP67 | Dust-tight, immersion up to 1m for 30 min |
| Pin Count | 6 Pins | VBUS, GND, CC1, CC2 |
| Mount Type | SMT (Surface Mount) | Right angle, 90° orientation |
| Current Rating | 5A | Supports USB PD up to 100W |
| Voltage Rating | 30V DC | — |
| Insertion Force | 20N Max | Per IEC 62680 |
| Withdrawal Force | 5–20N | — |
| Mating Cycles | 10,000 | High durability |
| Operating Temperature | -25°C to +85°C | Industrial grade |
| Packaging | Reel / Tray | SMT assembly ready |
| Compliance | RoHS 3, REACH | EU & global export ready |
Key Features — Waterproof USB-C 6 Pin SMT Connector
IP67 Waterproof & Dustproof
Fully sealed against dust and water immersion up to 1 meter for 30 minutes. Ideal for outdoor, marine, and industrial environments.
5A / 100W PD Fast Charging
Rated 5A continuous current, supporting USB Power Delivery up to 100W (20V/5A) with a compatible PD controller.
6-Pin Pure Power Configuration
Retains VBUS, GND, and CC pins for charging only — no USB 2.0 data lines, reducing cost for dedicated power applications.
Stainless Steel Shell & Silicone Seal
Rugged metal housing and precision-molded silicone sealing ring provide excellent mechanical strength and environmental protection.
Right Angle SMT — Space Saving
90° right-angle orientation and SMT footprint allow for compact PCB layouts, ideal for portable and space-constrained devices.
SMT Production Ready
Supplied in tape-and-reel packaging, fully compatible with automated pick-and-place lines for high-volume manufacturing.
Typical Applications for Waterproof USB-C 6 Pin Connector
The USB-TC06-FW06 is widely used in devices that require reliable charging in wet or dusty environments where data transfer is not needed.
Frequently Asked Questions
What is the IP rating of this waterproof USB-C connector?
Does this 6-pin USB-C connector support data transfer?
What is the maximum power this connector can handle?
What is the minimum order quantity (MOQ)?
Can I get a free sample of this waterproof USB-C connector?
Technical Resources
For detailed technical specifications and standards, refer to:
- USB Type-C Cable and Connector Specification (USB-IF)
- IEC 60529 – Degrees of protection provided by enclosures (IP Code)
- USB-C connector overview on Wikipedia
These resources provide additional context on waterproofing standards and USB-C mechanical requirements.
