IP67 Waterproof USB-C Connector 6 Pin SMT — USB-TC06-FW08 Outdoor & Industrial Type-C Female Receptacle
The USB-TC06-FW08 is an IP67 waterproof USB-C connector 6 pin with SMT right-angle PCB mounting. Rated 5A/30VDC, 10,000 mating cycles, sealed to IP67 (dust-tight + 30-minute submersion to 1 metre). Supports USB 2.0 data and USB Power Delivery charging. RoHS 3 & REACH compliant. MOQ 1,000 pcs. Free sample available.
IP67 Waterproof USB-C Connector 6 Pin — USB-TC06-FW08 Product Overview
The USB-TC06-FW08 is an IP67 waterproof USB-C connector 6 pin (Type-C female receptacle) designed for SMT right-angle PCB mounting in applications where the USB-C port must survive exposure to water, dust, moisture, and harsh outdoor environments. Manufactured by Vistar Electronics, this sealed USB-C receptacle delivers reliable USB 2.0 charging and data connectivity with an IP67 environmental protection rating — making it the standard component for waterproof charging ports on outdoor power stations, marine electronics, ruggedised handheld devices, industrial sensors, and IP-rated enclosures.
The IP67 rating of the USB-TC06-FW08 waterproof connector means it is completely dust-tight (IP6X — no ingress of dust under any conditions) and protected against temporary water immersion up to 1 metre depth for 30 minutes (IPX7). This covers the full range of outdoor and industrial splash-and-rain protection requirements, and meets the minimum waterproofing threshold required by the majority of IP-rated consumer electronics certifications. For applications requiring deeper submersion protection (IP68 at specified pressure/depth), see the IP68-rated variants in our waterproof USB-C range.
The 6-pin USB-C configuration of the USB-TC06-FW08 retains the essential pins of the USB-C specification: VBUS, GND, CC1, CC2, D+, and D−. The CC1 and CC2 configuration channel pins enable USB Power Delivery protocol negotiation, supporting up to 5A fast charging when paired with a compatible USB PD controller IC. Data transmission operates at USB 2.0 (480 Mbps), which is the appropriate data rate for the vast majority of outdoor charging applications — the 6-pin configuration is deliberately optimised for charging-primary products where high-speed USB 3.x SuperSpeed data is not required, allowing the additional pin space to be used by the waterproof sealing gasket structure instead.
The waterproof sealing is achieved through a precision silicone gasket that forms a hermetic seal around the USB-C receptacle body at the PCB mounting interface, combined with a sealed connector shell. The design is compatible with standard USB-C plug cables when the cable’s plug is also equipped with a sealing gasket — fully sealed IP67 assemblies require both a sealed receptacle (USB-TC06-FW08) and a sealed cable plug assembly on the mating end. The receptacle itself protects the PCB and interior electronics even with no cable inserted, thanks to the integrated dust/water cap design.
According to the IEC 60529 standard, which defines IP (Ingress Protection) ratings for electrical enclosures, IP67 is the most widely adopted waterproof rating for consumer outdoor electronics — covering all outdoor environmental conditions short of continuous submersion. Products certified to IP67 can withstand rain, splashing, brief submersion (swimming pool edges, boat decks, outdoor charging stations) without water ingress to the PCB.
The USB-TC06-FW08 is rated at 5A / 30VDC, accommodating both USB PD 3.0 (up to 100W at 20V/5A) and standard 5V/3A (15W) charging. The SMT right-angle mounting orientation exits the USB-C port horizontally toward the board edge — the standard configuration for panel-mount waterproof ports on sealed enclosures where the port faces the exterior of the housing and the PCB is mounted inside. Gold-plated contacts ensure consistent low contact resistance across the 10,000-cycle mating life.
All USB-TC06-FW08 connectors are manufactured in Vistar Electronics’ ISO 9001:2015 certified facility in Shenzhen, China, and comply fully with RoHS 3 (EU Directive 2015/863) and REACH SVHC regulations. For non-waterproof USB-C applications, see our full USB-C connector range. For IP68-rated variants, see our complete waterproof USB-C range.
USB-TC06-FW08 Waterproof USB-C SMT Right Angle Connector — Full Technical Specifications
| Parameter | Value | Notes |
|---|---|---|
| Part Number | USB-TC06-FW08 | Standard catalog item |
| Connector Type | USB-C Female Receptacle | Type-C female, waterproof |
| USB Standard | USB 2.0 Type-C | 480 Mbps data + 5A charging |
| Pin Count | 6 Pins | VBUS, GND, D+, D−, CC1, CC2 |
| Waterproof Rating | IP67 | Dust-tight + 1m / 30 min immersion |
| Mount Type | SMT (Surface Mount) | With mechanical retention tabs |
| Orientation | Right Angle | Port faces toward board edge |
| Current Rating | 5A (VBUS) | USB PD 3.0 compatible |
| Voltage Rating | 30V DC Max | — |
| Mating Cycles | 10,000 cycles | High durability |
| Contact Material | Copper Alloy, Gold Plated | Low, stable contact resistance |
| Insulator Material | LCP (High-Temperature) | SMT reflow compatible |
| Shell Material | Stainless Steel | EMI shielding + structural rigidity |
| Sealing Material | Silicone Gasket | Hermetic seal at PCB interface |
| Operating Temperature | −40°C to +85°C | Industrial temperature range |
| Storage Temperature | −40°C to +125°C | — |
| Packaging | Reel / Tray | SMT pick-and-place ready |
| Compliance | RoHS 3, REACH SVHC | EU & global export ready |
| Certification | ISO 9001:2015 | Factory quality management |
Why Engineers Choose the USB-TC06-FW08 IP67 USB Type-C Receptacle PCB Mount
IP67 Sealed — Complete Dust & Temporary Immersion Protection
IP67 certification (IEC 60529) guarantees: IP6X — zero dust ingress under any conditions; IPX7 — withstands immersion to 1 metre depth for 30 minutes. This covers all outdoor charging scenarios including rain, splashing, condensation, and brief accidental submersion — the standard protection level for outdoor power stations, marine charging panels, and ruggedised handheld devices.
5A / USB Power Delivery — Up to 100W Waterproof Fast Charging
Rated 5A / 30VDC with CC1 and CC2 configuration channel pins for USB PD negotiation. Supports USB PD 3.0 up to 100W (5A × 20V) with a compatible PD controller IC — enabling fast-charging functionality in waterproof outdoor power stations, waterproof chargers, and ruggedised devices without requiring a separate proprietary charging port.
10,000 Mating Cycles — Outdoor-Grade Connector Durability
Rated for 10,000 insertion and withdrawal cycles — significantly higher than the standard 5,000-cycle commercial rating. This extended service life accommodates the frequent cable connections typical of outdoor charging stations, portable power banks, and field equipment where the USB-C port may be mated and unmated many times daily throughout a multi-year product lifespan.
−40°C to +85°C — Full Industrial Temperature Range
Rated for operation from −40°C to +85°C — covering arctic cold, direct sun exposure, and hot industrial environments beyond the typical consumer 0°C to +70°C range. The silicone sealing gasket maintains its elasticity and sealing performance across the full temperature range, preventing seal degradation in extreme outdoor and industrial thermal cycles.
SMT Right-Angle — Standard Panel-Mount Port Configuration
The SMT right-angle mounting orients the USB-C socket opening toward the PCB board edge — the standard configuration for panel-mount ports on sealed enclosures where the connector face is accessible from the exterior. Compatible with automated SMT pick-and-place assembly and standard reflow soldering profiles for cost-effective high-volume production.
RoHS 3 & REACH Compliant — Global Export Ready
Fully compliant with RoHS 3 (EU Directive 2015/863) and REACH SVHC substance regulations. Suitable for EU CE marking, North American, and all major regulated export markets. Compliance documentation — including RoHS declarations and REACH SVHC statements — is available upon request for product certification and supply chain audits.
Where to Use the USB-TC06-FW08 Waterproof USB-C Connector 5A 30V — Outdoor & Industrial Applications
USB-TC06-FW08 Waterproof USB-C Connector 6 Pin — Frequently Asked Questions
What does IP67 mean for a USB-C connector?
IP67 is an ingress protection rating defined by IEC 60529 with two digits:
- IP6X (first digit = 6): Complete protection against dust ingress — no dust particles can enter the connector body under any conditions.
- IPX7 (second digit = 7): Protection against temporary water immersion up to 1 metre depth for 30 minutes.
For the USB-TC06-FW08 receptacle, this means the connector can withstand rain, splashing from any direction, submersion in puddles or shallow water, and high-humidity environments — covering all standard outdoor product use cases. For continuous or deeper submersion (pools, underwater equipment), IP68 at a specified depth/duration is required. See our IP68 waterproof USB-C range for those applications.
Does the USB-TC06-FW08 maintain its IP67 rating when a cable is plugged in?
The USB-TC06-FW08 receptacle provides IP67 protection at the PCB/enclosure interface — meaning it prevents water from passing through the panel into the PCB interior. When no cable is inserted, the connector maintains its IP67 rating against the environment.
When a cable is inserted, the overall IP rating of the assembly depends on the mating cable plug. To maintain IP67 protection with a cable connected, the cable plug assembly must also be IP67-rated with its own sealing gasket. Standard USB-C cables (without a sealing plug) will reduce the sealed assembly’s water resistance when connected. For fully sealed cable assemblies, specify a matching IP67 USB-C cable plug from our cable assembly range.
Why does the USB-TC06-FW08 only have 6 pins instead of the full 24-pin USB-C specification?
The 6-pin configuration retains only the pins required for USB 2.0 data (D+, D−) and USB Power Delivery charging (VBUS, GND, CC1, CC2). The full 24-pin USB-C specification includes additional SuperSpeed TX/RX differential pairs for USB 3.x data (5/10/20 Gbps) and SBU pins for DisplayPort Alt Mode — but these require significantly more pin space in the connector body.
In a waterproof USB-C connector, the sealing gasket structure occupies space that would otherwise accommodate the additional SuperSpeed pins. The 6-pin design is a deliberate engineering trade-off: prioritising IP67 waterproof sealing and a compact connector body over high-speed data capability — the correct choice for charging-primary outdoor products where USB 2.0 (480 Mbps) data is sufficient. For waterproof USB-C connectors with higher pin counts, contact our engineering team.
Can this connector support USB Power Delivery (PD) fast charging?
Yes. The USB-TC06-FW08 includes CC1 and CC2 configuration channel pins for USB PD negotiation, rated at 5A / 30VDC. With a compatible USB PD controller IC on the host PCB (CYPD, FUSB302, or similar), this connector supports USB PD 3.0 up to 100W (5A × 20V) — enabling full-speed USB PD fast charging through a waterproof IP67 sealed port. This is the key advantage over older waterproof Micro-USB connectors, which cannot support USB PD negotiation.
How is the IP67 waterproof seal achieved in SMT mounting?
The USB-TC06-FW08 achieves its IP67 rating through a precision silicone gasket integrated into the connector body base. During SMT assembly, the gasket compresses against the PCB surface and the panel cutout edge, forming a hermetic seal that prevents water ingress. The stainless steel shell is also designed to mate flush with the panel aperture, completing the sealed interface.
PCB assembly notes: (1) The connector requires a clean, flat PCB surface for the gasket to seal correctly — PCB warping or contamination will compromise the IP67 rating. (2) The panel cutout dimensions must match the connector’s shell profile — refer to the product datasheet for exact cutout specifications. (3) Reflow soldering must not overheat the silicone gasket — standard lead-free reflow profiles (peak ≤260°C for ≤10 seconds) are compatible.
What is the MOQ and can I get a free sample?
Standard MOQ is 1,000 pieces with a 2–4 week production lead time. Free samples are available for qualified engineering and product development projects. Contact sales@vistarelectronics.com with your company details, application description, and part number (USB-TC06-FW08), or click the “Get a Quote” button at the top of this page.
IP67 Waterproof USB-C Connector Manufacturer — Shenzhen Vistar Electronics
Shenzhen Vistar Electronics Co., Ltd. manufactures a complete range of waterproof USB-C connectors including IP67 and IP68-rated female receptacles in 6-pin, 16-pin, and 24-pin configurations. The USB-TC06-FW08 is our most popular IP67 waterproof USB-C 6-pin SMT right-angle connector, used in outdoor power stations, marine electronics, industrial handheld devices, and ruggedised consumer products worldwide.
All waterproof USB-C connectors are manufactured in our ISO 9001:2015 certified Shenzhen facility, compliant with RoHS 3 and REACH SVHC. For the full range of waterproof options, see our Waterproof USB-C Receptacle category. For standard (non-waterproof) USB-C connectors, see our USB-C connector range. Contact sales@vistarelectronics.com for OEM/ODM enquiries and custom waterproof connector requirements.
