19 Pin HDMI PCB Mount Connector – SMT Female Receptacle for Board-Level Assembly

Name: 19 Pin HDMI PCB Mount Connector – SMT Female Receptacle for Board-Level Assembly
Brand: Vistar Electronics
Availability: InStock

The HDMI-AF-1909 is a HDMI PCB mount connector — a 19-pin Type A female receptacle with SMT termination and right-angle orientation for compact PCB layouts. Rated 0.5A, 40V, with 10,000 mating cycles. Supports HDMI 2.0 up to 18 Gbps. RoHS & REACH compliant. Reel/Tray packaging. MOQ 1,000 pcs. Free sample available.

Part NumberHDMI-AF-1909

Connector TypeHDMI Type A Female Receptacle

HDMI Version SupportHDMI 1.4 / 2.0

Maximum Bandwidth18 Gbps (HDMI 2.0)

Supported ResolutionUp to 4K@60Hz

Overview

19 Pin HDMI PCB Mount Connector — Product Overview (SMT HDMI Connector for Automated Assembly)

Vistar 19 pin HDMI PCB mount connector with SMT termination, right-angle female receptacle. Rated 10,000 cycles, 0.5A, 40V. Ideal for displays, docking stations, and embedded systems. Free sample.

The HDMI-AF-1909 is a 19 pin HDMI PCB mount connector — a Type A female receptacle engineered for board-level HDMI interfaces in compact electronic assemblies. This SMT HDMI connector features surface-mount termination that supports automated reflow soldering, making it compatible with high-volume PCB production lines. The right-angle orientation positions the HDMI cable parallel to the PCB, reducing vertical clearance requirements and enabling slim enclosure designs.

This HDMI SMT connector carries the full 19-pin HDMI signal set — three TMDS data lanes for video, TMDS clock, DDC for EDID communication, CEC, +5V power, and Hot Plug Detect. Gold-plated phosphor bronze contacts and a shielded metal shell deliver stable signal integrity up to 18 Gbps (HDMI 2.0). The connector is rated for 10,000 mating cycles, ensuring reliable performance in frequently connected applications.

Manufactured in an ISO 9001:2015 certified facility, this PCB mount HDMI receptacle is fully compliant with RoHS 3 and REACH regulations. Available in tape-and-reel packaging for automated assembly, with OEM customization options for volume orders.

Technical Specifications

SMT HDMI Connector — Full Technical Specifications

Below are the complete specifications for the SMT HDMI connector HDMI-AF-1909, covering electrical, mechanical, and environmental ratings.

Parameter	Specification	Notes
Part Number	HDMI-AF-1909	Standard catalog item
Connector Type	HDMI Type A Female Receptacle	19-pin full-featured
HDMI Version Support	HDMI 1.4 / 2.0	Passive connector — protocol depends on source/sink
Maximum Bandwidth	18 Gbps (HDMI 2.0)	With compatible source and cable
Supported Resolution	Up to 4K@60Hz	—
Mounting Type	SMT (Surface Mount)	Right angle orientation
Orientation	Right Angle	Cable exit parallel to PCB
Pin Count	19 Pins	Full HDMI signal set
Contact Material	Copper Alloy	Gold plated
Shell Material	Stainless Steel	Shielded, EMI protection
Housing Material	LCP (High-Temperature)	UL94V-0, reflow compatible
Current Rating	0.5A per contact	Signal contacts
Voltage Rating	40V AC	Per HDMI specification
Contact Resistance	≤ 30 mΩ	Initial
Insulation Resistance	≥ 100 MΩ	At 500V DC
Mating Cycles	10,000 cycles	Durability
Operating Temperature	-25°C to +85°C	Commercial / industrial grade
Compliance	RoHS 3, REACH	Global export ready
Packaging	Reel / Tray	SMT assembly ready

Key Features

HDMI SMT Connector — Key Features and Advantages

⚙️

SMT Termination — Automated Assembly Ready

Surface-mount pads support reflow soldering and tape-and-reel packaging for high-volume pick-and-place assembly. The high-temperature LCP housing withstands 260°C reflow profiles.

🔌

Standard 19-Pin HDMI Type-A Interface

Full compatibility with standard HDMI cables and devices. Supports high-definition video and multi-channel audio transmission through a single connector.

↗️

Right-Angle PCB Orientation

Positions the cable parallel to the PCB, enabling edge-mount installation and reducing vertical clearance requirements for slim enclosure designs.

🔄

10,000 Mating Cycles — Long-Term Durability

Rated for 10,000 insertion and withdrawal cycles, ensuring reliable performance in applications requiring frequent connect/disconnect operations.

🛡️

Shielded Metal Shell — EMI Protection

Stainless steel shell provides effective EMI shielding and mechanical protection, maintaining signal integrity in high-frequency applications.

✅

RoHS 3 & REACH Compliant

Fully compliant with EU environmental directives. Documentation available for global export and supply chain audits.

19 Pin HDMI PCB Mount Connector: SMT vs Through-Hole — Which One to Choose?

When selecting a 19 pin HDMI PCB mount connector, understanding the differences between SMT and through-hole mounting is essential. The table below compares the key characteristics.

Feature	SMT HDMI Connector (HDMI-AF-1909)	Through-Hole HDMI Connector
PCB Mounting	Surface Mount — pads on PCB surface	Through-Hole — pins pass through PCB
PCB Holes Required	No — surface pads only	Yes — drilled holes
Assembly Process	Reflow Soldering — automated	Wave / Selective Soldering
PCB Density	Higher — no through-hole clearance	Lower — requires hole clearance
Mechanical Strength	Good — pad design + anchor tabs	Higher — dual-sided solder joints
Best For	Compact Electronics, High-Volume Production	Industrial Equipment, High-Reliability

The HDMI-AF-1909 is an SMT connector. Choose this for compact PCB designs and automated assembly. For applications requiring maximum mechanical strength, consider our through-hole HDMI connector options.

PCB Mount HDMI Receptacle — Right-Angle Design for Compact Enclosures

A right-angle PCB mount HDMI receptacle offers several distinct advantages for designers working on space-constrained electronic devices. The right-angle orientation positions the HDMI cable parallel to the PCB surface, significantly reducing the vertical space required compared to vertical connectors.

Key Advantages

Saves vertical space: The low-profile design allows for slim enclosures and thinner product profiles.
Supports horizontal cable insertion: Cables exit parallel to the board, ideal for devices placed in tight spaces.
PCB edge mounting: The connector can be placed at the board edge with the port flush against the enclosure.
Optimizes enclosure layout: Horizontal routing reduces internal cable clutter and improves airflow.
Reduces connector height above PCB: Suitable for applications where vertical clearance is at a premium.

For a comparison of different mounting orientations, see our 90 degree HDMI connector options.

Applications

Where to Use This PCB Mount HDMI Receptacle — Applications Across Industries

📺 Consumer Electronics TV control boards, set-top boxes, media players, and streaming devices.

🖥️ Display Systems Monitors, display control boards, video transmission equipment, and digital signage.

🏭 Industrial Electronics Industrial displays, HMI systems, embedded computing devices, and panel PCs.

🔌 Docking & Multimedia Equipment Docking stations, video adapters, multimedia control devices, and AV receivers.

🎮 Gaming & Entertainment Gaming consoles, VR peripherals, and entertainment systems requiring HDMI connectivity.

🏥 Medical & Healthcare Medical displays, diagnostic equipment, and healthcare workstations.

As a versatile PCB mount HDMI receptacle, the HDMI-AF-1909 is found across a wide range of applications where reliable SMT assembly and compact design are required. Its 19-pin Type A interface ensures compatibility with standard HDMI cables and devices.

19 Pin HDMI PCB Mount Connector — Frequently Asked Questions

What is a HDMI PCB mount connector?

A HDMI PCB mount connector is a board-mounted HDMI receptacle designed for direct PCB integration. The HDMI-AF-1909 is a 19-pin Type A female connector with SMT termination and right-angle orientation, providing reliable HDMI connectivity in compact electronic assemblies.

What is the difference between SMT and through-hole HDMI connectors?

An SMT HDMI connector is surface-mounted on PCB pads using reflow soldering, making it suitable for high-volume automated assembly and compact PCB designs. A through-hole HDMI connector uses pins that pass through drilled holes and are wave-soldered, providing higher mechanical strength. The HDMI-AF-1909 is an SMT connector — choose this for compact electronics and high-volume production.

Is this HDMI connector suitable for right-angle PCB mounting?

Yes. The HDMI-AF-1909 is a right-angle connector, designed for PCB edge mounting with horizontal cable exit. This orientation is ideal for slim enclosures and compact devices where vertical space is limited.

Can an SMT HDMI connector be used for automated PCB assembly?

Yes. The HDMI-AF-1909 is specifically designed for SMT assembly. It is available in tape-and-reel packaging for high-volume pick-and-place machines, and the high-temperature LCP housing withstands standard reflow soldering profiles up to 260°C.

What applications use a 19 pin HDMI receptacle?

A 19 pin HDMI receptacle is used in a wide range of applications including consumer electronics (TVs, set-top boxes), display systems (monitors, digital signage), industrial electronics (HMIs, embedded systems), docking stations, gaming consoles, and medical equipment.

How do I choose between SMT and DIP HDMI PCB connectors?

Choose SMT for high-volume automated assembly, compact PCB designs, and consumer electronics where board space is at a premium. Choose DIP / through-hole for industrial applications, high-reliability environments, and designs requiring maximum mechanical strength. Both options are available from Vistar.

What is the MOQ and can I get a free sample?

Standard MOQ is 1,000 pieces with a 2–4 week production lead time. Free samples are available for qualified engineering and product development projects. Contact sales@vistarelectronics.com with your company details, project description, and part number (HDMI-AF-1909).

Need Custom HDMI Connector Solutions?

Vistar Electronics manufactures HDMI connectors in Type A, Type C, and Type D configurations with SMT, through-hole, right-angle, vertical, and mid-mount options. Custom heights, plating, and packaging available for OEM projects.
