Superior 20-Pin DisplayPort PCB Connector – Reliable 1.6mm Clamp Board
DisplayPort PCB Connector 20 Pin Overview
The DisplayPort PCB Connector 20 Pin is a high‑performance, clamp‑type board‑mount DisplayPort plug engineered for demanding industrial and consumer electronics. This connector features a 180° straight design with excellent signal integrity and secure PCB retention, fully compliant with VESA DisplayPort standards.
As display resolutions continue to advance toward 8K and beyond, manufacturers require robust DisplayPort board‑mount connectors capable of stable high‑speed digital transmission and compact integration. The 20‑pin clamp type structure provides superior mechanical retention compared to standard SMT designs, making it ideal for applications subject to vibration and repeated mating cycles.
Manufactured under ISO 9001:2015, this clamp type DisplayPort connector supports up to 32.4 Gbps (HBR3) through 20 gold‑plated contacts. The 1.6mm board mount clamp design ensures robust attachment to the PCB, while the 180° orientation saves valuable space on high‑density boards. The 20‑pin layout guarantees compatibility across DisplayPort 1.2, 1.4, and 2.1 standards.
This connector is fully RoHS 3 and REACH compliant, using lead‑free plating and halogen‑free LCP housing. It is ready for global export and suitable for high‑bandwidth video and audio transmission applications including 8K monitors, gaming displays, industrial control panels, medical imaging equipment, and automotive infotainment systems.
According to the official Video Electronics Standards Association (VESA), DisplayPort technology provides advanced digital display connectivity with support for high bandwidth, ultra‑high‑definition video, and high‑performance multimedia applications. For detailed technical specifications and compliance information, developers can reference the official DisplayPort Standard Resources.
Vistar offers free samples, OEM/ODM customization, and comprehensive technical support for the 20 Pin DisplayPort PCB Connector. Additional product information and design resources can also be found at the DisplayPort Product Database.
Engineered for reliable signal transmission, secure PCB mounting, and durable mechanical performance, the 20 Pin DisplayPort PCB Connector provides an ideal connectivity solution for next‑generation multimedia and display equipment.
20 Pin DisplayPort Connector Specifications & Part Numbers
| Parameter | Specification |
|---|---|
| Part Number | DP-M-03 |
| Type | DisplayPort Plug, Clamp Board, 180° Straight |
| Pin Count | 20 Pins |
| PCB Thickness | 1.6mm (Clamp Type) |
| Current Rating | 0.5A per pin |
| Insertion Force | 35N Max |
| Withdrawal Force | 8N Min |
| Operating Life | 5,000 Mating Cycles |
| Contact Material | Copper Alloy, Gold Plated |
| Contact Resistance | ≤30 mΩ |
| Insulation Resistance | ≥100 MΩ |
| Withstanding Voltage | AC 250V (1 min) |
| Operating Temperature | -40°C to +85°C |
| Shell Material | Stainless Steel, Nickel Plated |
| Housing Material | LCP (Liquid Crystal Polymer) |
| Compliance | VESA DP 1.2/1.4/2.1, RoHS 3, REACH |
| Bandwidth | Up to 32.4 Gbps (HBR3) |
| Supported Resolution | 8K@60Hz, 4K@144Hz, 1080p@240Hz |
| Packaging | Reel / Tray |
| Certification | ISO 9001:2015 |
