Des: PCB mount Tact Push Button Switch Vertical 2 Pin SMD Normal Close Tactile Switch 4x6x2.5
Part No: TS-4601
Specification:
Rating: 50mA, DC 12V
Travel: 0.2±0.10mm
Operating force: 180gf/260gf
Operating Life: 50,000/100,000 Cycles
Packaging: Reel/Bag
