Vistar’s comprehensive tactile switch series delivers reliable push-button solutions for a wide array of applications. Available in 4x4mm, 6x6mm, and 12x12mm footprints, with SMD and DIP mounting, these switches provide crisp tactile feedback and are ideal for consumer electronics, automotive interfaces, and medical devices.
| Parameter | Standard Series | Waterproof Series |
|---|---|---|
| Rated Voltage | 12V DC | 12V DC |
| Rated Current | 50mA | 50mA |
| Contact Resistance | ≤ 100mΩ (Initial) | ≤ 100mΩ |
| Insulation Resistance | ≥ 100MΩ at 100V DC | ≥ 100MΩ |
| Dielectric Strength | 250V AC for 1 minute | 250V AC |
| Operating Force (Standard) | 160gf / 260gf / 320gf | 160gf / 260gf |
| Actuator Travel | 0.20 – 0.30mm | 0.25±0.10mm |
| Mechanical Life | 50,000 – 100,000 cycles | 50,000 – 100,000 cycles |
| Operating Temperature | -25°C to +70°C | -20°C to +70°C |
| Storage Temperature | -30°C to +85°C | -25°C to +85°C |
| Ingress Protection | — | IP67 |
Delivers crisp, consistent haptic feedback, rated for up to 100,000 actuations — ensuring long‑term reliability in keyboards, remote controls, and industrial HMIs.
Available in industry‑standard 4×4mm, 6×6mm, and 12×12mm sizes with SMD and DIP through‑hole options. Drop‑in compatible with existing PCB designs.
Sealed tactile switches meet IP67 standards, making them ideal for outdoor equipment, automotive dashboard controls, and medical devices where moisture and dust exposure is a concern.
4‑pin SMD tactile switches feature two electrical pins and two mechanical anchor pins, preventing PCB rocking during wave soldering and providing superior stability for high‑density assemblies.
All Vistar tact switches are manufactured under ISO 9001:2015 and fully comply with RoHS 3 and REACH regulations, ensuring safe export to global markets. Compliance certificates available.
Operating force (160/260/320gf) and actuator height can be customized. Tape‑and‑reel packaging supports automated pick‑and‑place processes — free engineering samples available.
Specialized in electronic connectors since 2009
100% quality testing before shipment
Available for qualified projects
2-4 weeks standard delivery
Custom design & manufacturing
Serving 50+ countries worldwide
Shenzhen Vistar Electronics Co., Ltd. is a professional tactile switch manufacturer based in Shenzhen, China — the global electronics manufacturing hub. Since 2009, we have specialized in the design, manufacturing, and global supply of high‑quality electromechanical switches, including tactile switches, slide switches, detector switches, and pushbutton switches for OEM and ODM customers in 50+ countries.
Our tactile switch series covers all industry‑standard sizes — 4×4mm, 6×6mm, and 12×12mm — with SMD, DIP through‑hole, right‑angle, and side‑actuated mounting options. IP67 waterproof versions are available for demanding outdoor, automotive, and medical environments. Rated at 50mA/12VDC with 100,000 mechanical cycles, all our tact switches are manufactured under ISO 9001:2015 and fully comply with RoHS 3 and REACH regulations.
Whether you need a 4‑pin SMD tact switch for automated assembly or a 2‑pin miniature tactile switch for a compact wearable, Vistar offers reliable, cost‑effective solutions with quick sample support.
