Horizontal push switch 2p2t

A horizontal push switch 2p2t is a side‑actuated push button designed for PCB mounting where vertical space is limited or side‑panel access is required. The actuator extends parallel to the board, making it ideal for edge‑mounted controls in compact enclosures. This horizontal push button switch uses a 2P2T (DPDT) circuit, allowing two independent circuits to be switched simultaneously with a single press. The PS-22F38 is available in both self‑locking (push‑on/push‑off) and momentary versions, covering a broad range of control logic requirements without additional components.

Compared to vertical push switches, a right angle push switch significantly reduces the total height above the PCB, enabling thinner product designs. The through‑hole terminals provide strong mechanical retention that withstands repeated actuation and lateral cable forces. This PCB push switch is compatible with wave soldering and manual assembly, making it practical for prototyping through volume production.

• 15+ Years Manufacturing – trusted supplier of electromechanical switches for global OEMs.
• OEM & ODM – custom actuator styles, colours, and electrical specifications.
• ISO 9001 Quality Control – consistent product performance backed by rigorous testing.
• Engineering Support – CAD models, footprint data, and application notes provided.
• Free Samples – prototype samples shipped within days for evaluation.
• Worldwide Shipping – flexible logistics to keep your production on schedule.

Horizontal push switches are widely used in industrial control systems, communication equipment, audio devices, and embedded electronic products where side‑actuated operation and compact PCB layouts are required. The 2P2T push switch circuit configuration enables reliable dual‑circuit switching for signal routing, function selection, and electronic control. When selecting a horizontal push button switch, engineers must evaluate actuation direction, circuit configuration, and mechanical life—all of which the PS-22F38 addresses with its right‑angle DPDT design and self‑lock/momentary options.

Vistar Electronics offers OEM and ODM manufacturing, RoHS‑compliant materials, and engineering support for global customers. Our right angle push switch range is available in different operating forces, actuator styles, and locking mechanisms to meet diverse design requirements. Explore our push button switch portfolio: Push Button Switch Category, PCB Mount Right Angle Pushbutton Switch 2P2T, PCB Push Switch DPDT 6 Pin Right Angle, 6 Pin DPDT Push Button Switch, and Horizontal SMT Push Switch 2P2T. For technical background, see our guides on Horizontal Push Switch vs Vertical Push Switch, What Is a 2P2T Push Switch?, DPDT Push Switch Applications, and How to Choose a PCB Mount Push Button Switch. For industry standards, refer to IEC Standards and ISO Standards. To request a free sample of the PS-22F38 or discuss your requirements, contact sales@vistarelectronics.com.
