24-Pin USB-C Plug Vertical SMT Through-Hole — High-Current PCB Connector

The 24-Pin USB-C Plug Vertical SMT Through-Hole connector is a high-performance USB Type‑C male connector engineered for modern electronic devices requiring reliable high‑speed communication, compact PCB integration, and stable power delivery. Designed with a vertical SMT + through‑hole hybrid mounting structure, this connector combines excellent soldering reliability with superior mechanical retention strength for demanding electronic applications.

As USB Type‑C technology rapidly becomes the global standard for connectivity and charging across consumer electronics, industrial automation equipment, communication systems, automotive electronics, and smart IoT products, manufacturers increasingly require durable USB‑C plug connectors capable of supporting USB 3.1 high‑speed data transmission and USB Power Delivery charging systems.

This connector adopts a full 24 pin USB Type‑C plug architecture, enabling complete USB‑C functionality including USB 3.1 communication, reversible insertion capability, USB PD charging, TX/RX differential pairs, CC communication channels, VBUS power transmission, and auxiliary signal support. Compared with simplified lower‑pin USB‑C interfaces, the 24‑pin structure provides superior compatibility, enhanced signal integrity, and more stable electrical performance for advanced electronic applications.

The vertical SMT through‑hole structure is specifically optimized for applications requiring improved PCB retention strength and reliable soldering performance. The SMT contacts support automated assembly processes while the through‑hole retention tabs provide additional mechanical stability against vibration, insertion stress, and long‑term operational wear.

Supporting up to 5A current and 30V DC voltage, this USB‑C plug connector is suitable for high‑current charging systems, industrial communication equipment, docking stations, gaming hardware, embedded systems, portable electronics, and charging accessories. With durability rated for over 10,000 mating cycles, the connector ensures reliable long‑term operation even in demanding industrial and commercial environments.

According to the official USB Implementers Forum (USB‑IF), USB Type‑C has become the universal connectivity standard because of its compact reversible interface, advanced power delivery capability, and high‑speed communication performance.

For engineers seeking official USB Type‑C technical documentation, the USB Type‑C Cable and Connector Specification provides comprehensive connector architecture and compliance requirements.

This connector is also compatible with charging systems based on the official USB Power Delivery Specification, supporting intelligent charging and fast power transmission applications.

For general technical reference regarding USB Type‑C interface functionality and industry applications, developers may also review the USB‑C Technology Overview.

The 24 Pin USB‑C Plug Vertical SMT Through Hole connector offers an excellent balance of electrical reliability, compact structure, mechanical durability, and manufacturing efficiency for next‑generation electronic device development.
