Des: 10 PINS DIP TYPE VERTICAL SLIDE SWITCH 180° 2P4T
Part No: SS-24E02
Specification:
Rating: 0.5A, DC 50V
Function: 2P4T
Operating Life: 10,000 Cycles
Packaging: Bag/Tray
- Home
- Products
- Vertical Slide Switch
- VERTICAL SLIDE SWITCH 180° 2P4T
VERTICAL SLIDE SWITCH 180° 2P4T
