Des: Female HDMI A type PCB Connector 19pin DIP right angle
Part No: HDMI-AF-1907
Specification:
Rating: 0.5A
Insertion force: 35N Max
Withdrawal force: 10N Min
Operating Life: 5,000Cycles
Packaging: Reel/Tray
- Home
- Products
- HDMI Connector
- HDMI A type PCB Connector 19pin DIP
HDMI A type PCB Connector 19pin DIP
