Professional USB C Connector Manufacturer for Your OEM/ODM Projects

Custom & High-Volume Production of USB-C Receptacles & Plugs. ISO 9001 Certified, Fast Sample Service.

USB-C Connectors

USB-C Male Connector

24 Pin USB Type-C Pug Vertical SMT through hole

Des: USB-C Male Connector 24 Pin USB Type-C Pug Vertical SMT Dual Raw through hole H=11.1
Part No: USB-TC24-M09
Specification:
Rating: 5A ,30VDC
Insertion force: 20N Max
Withdrawal force: 5-20N
Operating Life: 10,000Cycles
Packaging: Reel/Tray

USB-c Plug connector 24 pin middle mount right angle

Des: USB-c Plug connector 24 pin mid-mount right angle USB 3.1 Gen 2 Type-c male connector 24p L=15.5mm
Part No: USB-TC24-M04
Specification:
Rating: 5A ,30VDC
Insertion force: 20N Max
Withdrawal force: 5-20N
Operating Life: 10,000Cycles
Packaging: Reel/Tray

Mid mount USB C Male Connector 24 pin smt Horizontal

Des: Middle mount USB C Male Connector 24 pin smt right angle USB 3.1 Type-C Plug Connector dual row 24p
Part No: USB-TC24-M07
Specification:
Rating: 5A ,30VDC
Insertion force: 20N Max
Withdrawal force: 5-20N
Operating Life: 10,000Cycles
Packaging: Reel/Tray

USB 2.0 type C connector male 9 Pin mid mount right angle

Des: USB 2.0 type C connector male 9 pin mid mount USB c plug 9p smt right angle
Part No: USB-TC09-M02
Specification:
Rating: 3A ,30VDC
Insertion force: 20N Max
Withdrawal force: 5-20N
Operating Life: 10,000Cycles
Packaging: Reel/Tray

USB-C Female Connector

USB Type-C Receptacle 24p Vertical SMD T/H

Des: USB Type-C Receptacle 24p Vertical SMD type T/H SMT 24pin PCB Mount Socket USB-C female connectors
Part No: USB-TC24-F18A
Specification:
Rating: 5A ,30VDC
Insertion force: 20N Max
Withdrawal force: 5-20N
Operating Life: 10,000Cycles
Packaging: Reel/Tray

Vertical USB-c connector 24 pin SMT straight

Des: Top mount PCB usb type c receptacle 24p Vertical USB-c connector 24 pin SMT straight
Part No: USB-TC24-F18
Specification:
Rating: 5A ,30VDC
Insertion force: 20N Max
Withdrawal force: 5-20N
Operating Life: 10,000Cycles
Packaging: Reel/Tray

PCB Mount USB type-c connector 24 pin flank SMT T/H

Des: PCB Mount USB Type-c Connector 24 Pin Flank SMT USB-C Receptacle Through Holes Dual Shells
Part No: USB-TC24-F28M02
Specification:
Rating: 5A ,30VDC
Insertion force: 20N Max
Withdrawal force: 5-20N
Operating Life: 10,000Cycles
Packaging: Reel/Tray

90 Degree USB C Connector 24 Pin SMT Flank Mount Through Hole

Des: USB 3.2 Gen 2 Type-C Receptacle 90 Degree USB C Connector 24 Pin SMT Flank Mount Right Anlge Throug Hole
Part No: USB-TC24-F28M01
Specification:
Rating: 5A ,30VDC
Insertion force: 20N Max
Withdrawal force: 5-20N
Operating Life: 10,000Cycles
Packaging: Reel/Tray

Waterproof USB-C Connector

USB Type-C Waterproof Connector 24 pin SMT Right Angle IP68

Des: Top Mount USB C Receptale IPX8 Type-C Waterproof Connector 24 pin SMT Right Angle L=8.65
Part No: UCF24W0411
Specification:
Rating: 5A ,30VDC
Insertion force: 20N Max
Withdrawal force: 5-20N
Operating Life: 10,000Cycles
Packaging: Reel

6 Pin Type-C waterproof connector female SMD right angle

Des: PCB Mount USB-C scoket 6 Pin Type-C waterproof connector female SMD right angle
Part No: UCF06W0103
Specification:
Rating: 3A ,30VDC
Insertion force: 20N Max
Withdrawal force: 5-20N
Operating Life: 10,000Cycles
Packaging: Reel

Waterproof USB-C Connector 24 pin SMD Vertical

Des: PCB Mounting Waterproof USB-C Connector 24 pin SMD Vertical Type C Receptacle IPX6/7 H=8.8
Part No: UCF24W0403
Specification:
Rating: 3/5A ,30VDC
Insertion force: 20N Max
Withdrawal force: 5-20N
Operating Life: 10,000Cycles
Packaging: Reel

TYPE-C 16 PIN CONNECTOR WATERPROOF SMD VERTICAL

Des: IPX7 TYPE-C 16 PIN CONNECTOR WATERPROOF SMT VERTICAL USB-C SOCKET H=5.9
Part No: UCF16W0405
Specification:
Rating: 5A ,30VDC
Insertion force: 20N Max
Withdrawal force: 5-20N
Operating Life: 10,000Cycles
Packaging: Reel

What kind of USB C Connectors are you looking for?

About us

Shenzhen Vistar Electronics Co., Ltd. is a professional manufacturer specializing in Electronic Connectors and Switches, and it is situated in Pingshan District, Shenzhen. We are committed to providing advanced connectivity solutions to customers worldwide.

Our main products are USB Type-C connectors, as well as a wide range of connectors (HDMI/DisplayPort/FFC&FPC/D-sub/RJ45 connectors, Pin header connectors, automotive connectors), switches (tactile switches, slide switches, push switches, detector switches), and cable assemblies.

Our company values product quality highly. Since its founding, it has strictly adhered to the ISO 9001:2015 quality management system policy and has earned ISO 9001:2015 certification. Our quality goals are zero product defects and zero customer complaints.

We focus on improving quality for survival, technological innovation for growth, and continuously meeting customer needs.

Precision-Engineered USB-C Connectors for Diverse Applications

Product Type:
USB-C Receptacles: SMT, Through-Hole, Right-Angle
USB-C Plugs: for cable assembly
Technical Support:
Protocols: USB 2.0, USB 3.1/3.2, USB4, Power Delivery (PD)
Current Rating: 1.5A, 3A, 5A
Pin Count: 16-pin, 24-pin (Fully Featured)
Durability: Withstand 10,000+ mating cycles
Customization: Highlight your ability to customize housing, plating, etc.

Why Choose Us

We focus on R&D and have over 10 years of manufacturing experience in I/O connectors, wire-to-board connectors, board-to-board connectors, electromechanical switches, cable assemblies, etc.

Connector Insertion and Extraction Force Testing Methods: A Comprehensive Analysis of Professional Guidelines and Cutting-Edge Practices

In-House R&D & Tooling

We control the entire process from design to production, ensuring quality and enabling fast customization.

Full In-House Manufacturing & Quality Control

From molding, stamping to automated assembly and 100% electrical testing, we guarantee consistent quality.

Competitive Pricing for High-Volume Orders

As a direct factory, we offer the best value for your bulk purchasing needs.

Reliable Supply Chain & On-Time Delivery

Stable raw material sourcing and efficient production planning ensure we meet your deadlines.

Application of USB Type C Connectors

The USB Type C Connectors are widely used across various industries, including computers and peripherals, home appliances, digital communications, automobiles, industrial control, security, and medical electronics.

What our partners say

Building Trust, One Project at a Time: Feedback from the Industries We Serve.

"Our high-end network switches require connectors that can withstand frequent mating cycles and support high-speed USB4 protocols. We tested samples from multiple suppliers, and only the products from Vistar maintained excellent performance after 10,000 consecutive mating cycles. Their technical support was highly responsive, and the provided 3D models and specifications were extremely accurate, significantly shortening our design cycle. Their reliability and professionalism are impeccable."

-Dr. Arjun Patel, Chief Hardware Engineer

"As a startup, we needed a supplier supportive of small-batch, multi-volume production. Vistar Electronics did not treat us differently because of our order size; instead, they offered highly competitive pricing and flexible production scheduling. Their rapid sample service and patient technical consultation helped our small team successfully bring our first product to market. They are an excellent choice for growing companies seeking high quality and superior service."

- Tomasso Ricci, Sourcing Engineer

"During the development of our latest generation of ultra-thin tablets, we had extreme requirements for the size and durability of the USB-C port. The engineering team at Vistar Electronics worked closely with us, delivering a perfect customized solution within just 3 weeks. The signal integrity test results for their 24-pin full-featured port far exceeded industry standards, and they achieved a 99.8% first-pass yield during mass production, ensuring our product launched on schedule. They are a true partner, not just a supplier."

-John D., Project Manager

All our products meet the highest quality and safety standards. We proudly hold industry certifications from organizations like ISO, CE, RoHS, and UL which validate the safety, reliability, and performance of every item we sell.
